John Deere Aftermarket Seat w/Armrests & Air Suspension For Lawn Mowers

*Drilling Required*

*If You Purchase The Replacement Backrest Kit (PN: 8466), You Will Lose The Ability To Have Lumbar Support And A Backrest Extension Kit, Unless You Cut Those Parts Out Of Your Old Backrest Kit*

*This Seat & Mechanical Suspension In Black Vinyl (PN: 7882) Now Comes Standard With An Operator Presence Switch And Retractable Seat Belt*

*Please Verify All Measurements And Model Numbers (The WHOLE Model Number). In Some Cases, Particular Machines Have Multiple Options. It Is Up To You To Decide For Sure If This Item Fits Your Machine. If You Need Help, Please Call Or Email Us.*

Features:

• Grammer Air MSG75/531 Seat (PNs: 7916, 7776 & 8189) OR Grammer Mechancial MSG65/531 Seat (PNs: 7882, 8188 & 8462)
• Durable fabric or vinyl covering
• Low-profile air suspension with 12-Volt compressor with suspension travel of 3.1" (standard on PNs: 7916, 7776 & 8189)
• Mechanical suspension with suspension travel of 2.38" (standard on PNs: 7882, 8188 & 8462)
• Vacuum formed narrow seat cushion of 18.5"
• Asymmetrical backrest shape to make driving backwards more comfortable
• Adjustable backrest adds comfort and versatility
• Mechanical lumbar support to help prevent lower back pain
• Retractable seat belt for added safety (standard on PNs: 7882, 7916 & 8189) (optional on PNs: 7776, 8188 & 8462)
• Shock absorber (standard on PNs: 7916, 7776 & 8189)
• Adjustable slide rails provide 8.3" fore/aft adjustment
• Set slides at 11.25" W or 12.91" W
• Weight indicator with adjustment of 100 - 375 lbs
• Accepts operator presence switch (standard on PNs: 7916, 7776, 7882 & 8189) (optional on PNs: 8188 & 8462)

Complies with FEM 4.002 (for forklift trucks) and ISO 6683 (for earth-moving equipment).

Available Color & Suspension Options:

• Air Seat & Suspension in Black Vinyl (PN: 7916)
• Air Seat & Suspension in Black Fabric (PN: 7776)
• Air Seat & Suspension in Brown Vinyl with Armrests (PN: 8189)
• Air Seat & Suspension in Yellow Vinyl with Armrests (PN: 8721)
• Mechanical Seat & Suspension in Black Vinyl (PN: 7882)
• Mechanical Seat & Suspension in Gray Vinyl (PN: 8188)
• Mechanical Seat & Suspension in Two-Tone Gray Vinyl (PN: 8462)
• Mechanical Seat & Suspension in Yellow Vinyl with Armrests (PN: 8720)

Available Options:

• Left-Hand Armrest (PN: 7885)
• Right-Hand Armrest (PN: 7884)
• Headrest in Black Vinyl (PN: 8015)
• Retractable Seat Belt Kit -Standard on PNs: 7916 & 8189 (PN: 7887)
• Document Pouch (PN: 8450)
• Isolator Kit (PN: 7918)
• Operator Presence Switch - Optional on Mechanical PNs: 7882, 8188 & 8462 (PN: 8672)
• Grammer Seat/Backrest Cover Kit in Alcanta Two-Tone Gray Fabric (PN: 8065)
• Grammer Backrest Extension Cover Kit in Alcanta Two-Tone Gray Fabric (PN: 8066)

Available Maintenance Items (Only Fit This Seat Assembly, Not OEM):

• Replacement Backrest Cushion in Black Vinyl (PN: 8151)
• Replacement Seat Cushion in Black Vinyl (PN: 8152)
• Replacement Backrest Cushion in Black Fabric (PN: 8172)
• Replacement Seat Cushion in Black Fabric (PN: 8173)
• Replacement Backrest Cushion in Yellow Vinyl (PN: 8652)
• Replacement Seat Cushion in Yellow Vinyl (PN: 8653)
• Replacement Backrest Panel Kit (PN: 8466)
• Replacement MSG65/75 Seat Belt Cover Kit (PN: 8370)
• Replacement Weight Adjustment Handle Kit**(PN: 8088)
• Replacement Weight Adjustment Handle Kit & Block** (PN: 8593)
• Replacement Backrest Adjustment Handle Kit (PN: 8399)
• Replacement Wire Harness (PN: 8674)
• Replacement MSG75 12-Volt Air Compressor Kit* (PN: 8278)
• Replacement MSG75 Shock Absorber Kit* (PN: 8514)
• Replacement Airbag Kit* (PN: 8315)
• Replacement Air Hose* (PN: 8471)
• Replacement Switch Kit* (PN: 8318)

*Replacement Parts For The Air Suspension Seats (PNs: 7916, 7776 & 8189) Only.

**Replacement Parts For The Mechanical Suspension Seats (PNs: 7882, 8188 & 8462) Only.

Fits John Deere® Lawn Mowers (Drilling Required): 318, 727A, 997 Z-Trak, 1420, 1435, 1445, 1545, 1550, 1565, 1570, 1575, 1580, F725, Z2820A, Z840A
