Case IH 5100 Series Maxxum Tractor Seat & Mechanical Suspension - Fits Various Models - Black Vinyl

Brand: TORNADO HEAVY EQUIPMENT PARTS

Product Code: 6543

Availability:Out of stock

Case IH Aftermarket Seat & Mechanical Suspension For 5100 Series Maxxum Tractors

*This Seat Does Not Allow For An Operator Presence Switch*

**Drilling Required**

*Please Verify All Measurements And Model Numbers (The WHOLE Model Number). In Some Cases, Particular Machines Have Multiple Options. It Is Up To You To Decide For Sure If This Item Fits Your Machine. If You Need Help, Please Call Or Email Us.*

Features:

  • Durable black vinyl covering
  • Removable headrest
  • Vacuum formed cushions add comfort and durability
  • Seat cushion width of 17.75"
  • Seat index point of 1.38"
  • Extendable and foldable backrest with angle adjustment
  • Mechanical adjustable lumbar support
  • Fold-up armrests
  • Seat belt fixation points
  • Swivel
  • Adjustable slide rails with 8.25" of travel
  • Suspension travel of 4"
  • Manual weight adjustment of 286 lbs
  • 2.75" stroke reducer
  • Durable suspension cover to keep components free of dirt and dust

Seat & Suspension Kit (PN: 6543) Includes:

  • Seat & Mechanical Suspension
  • Swivel
  • Install Hardware
  • Installation Instructions

Available Options:

Available Maintenance Item:

Fits Case IH® 5100 Series Maxxum Tractors: 5120, 5130, 5140, 5220, 5230, 5240, 5250
